SEM PLS with moderation using seminr package

semplscorp

SEM PLS

Structural Equation Model Partial Least Square is a sophistication model to predict the relation of the some variable. Sometimes we are difficult to predict the relation of the some variable.

The Corporate Reputaion Model

we use corporate mode data corporate, but.. in my rstudio software i am difficult to find it. Fortunately, my seminr package version 2.3.2 has corporate_rep_data. the variable of the data similiar so i use it to learn about SEM PLS. According Chidung(n.d), the Semnir package help us to analyze data with SEM PLS mode. First, we should to create measurement model. use construct command to some variable from corporate_rep_data that i got it from the package (seminr). if you have from seminr package, you can use corporate data set that is not different to mine. I create the construct with reflective function.

# Create measurement model:
library (seminr)

corp_mm <- constructs(
  reflective("COMP", multi_items("comp_", 1:3)),
 reflective("LIKE", multi_items("like_", 1:3)),
  reflective("CUSA", single_item("cusa")),
  reflective("CUSL", multi_items("cusl_", 1:3)))
corp_rep_sm <- relationships(
  paths(from = c("COMP", "LIKE"), to = c("CUSA", "CUSL")),
  paths(from = c("CUSA"), to = c("CUSL")))

After constructing the model, you can create estimate pls. use the estimate_pls function.

my_model <- estimate_pls(data = corp_rep_data2, measurement_model = corp_mm, structural_model = corp_rep_sm, inner_weights = path_weighting, missing = mean_replacement,missing_value = "-99")

Generating the seminr model

All 347 observations are valid.

summary_model <- summary(my_model)

Use the model summary to check the loading factor and reliability. You can also display the plot of the model using plot function.

summary_model$loadings

        COMP  LIKE  CUSA  CUSL
comp_1 0.893 0.000 0.000 0.000
comp_2 0.619 0.000 0.000 0.000
comp_3 0.645 0.000 0.000 0.000
like_1 0.000 0.864 0.000 0.000
like_2 0.000 0.799 0.000 0.000
like_3 0.000 0.733 0.000 0.000
cusa   0.000 0.000 1.000 0.000
cusl_1 0.000 0.000 0.000 0.798
cusl_2 0.000 0.000 0.000 0.879
cusl_3 0.000 0.000 0.000 0.750

summary_model$reliability

     alpha  rhoC   AVE  rhoA
COMP 0.773 0.768 0.532 0.799
LIKE 0.841 0.842 0.641 0.847
CUSA 1.000 1.000 1.000 1.000
CUSL 0.849 0.852 0.658 0.857

Alpha, rhoC, and rhoA should exceed 0.7 while AVE should exceed 0.5

plot(summary_model$reliability)

summary_model$validity$cross_loadings

        COMP  LIKE  CUSA  CUSL
comp_1 0.841 0.638 0.464 0.456
comp_2 0.793 0.475 0.321 0.317
comp_3 0.844 0.528 0.325 0.340
like_1 0.644 0.885 0.542 0.579
like_2 0.536 0.885 0.463 0.568
like_3 0.580 0.842 0.426 0.520
cusa   0.461 0.551 1.000 0.706
cusl_1 0.462 0.604 0.574 0.853
cusl_2 0.418 0.603 0.673 0.925
cusl_3 0.327 0.467 0.608 0.851

summary_model$validity$fl_criteria

      COMP  LIKE  CUSA  CUSL
COMP 0.729     .     .     .
LIKE 0.675 0.800     .     .
CUSA 0.461 0.551 1.000     .
CUSL 0.461 0.639 0.706 0.811

FL Criteria table reports square root of AVE on the diagonal and construct correlations on the lower triangle.

summary_model$validity$htmt

      COMP  LIKE  CUSA CUSL
COMP     .     .     .    .
LIKE 0.817     .     .    .
CUSA 0.507 0.598     .    .
CUSL 0.551 0.752 0.765    .

Then, we draw the plot of the models. with the plot, we know the relation between variable.

plot(my_model)

After see the model you can use the bootstrap model. Bootstrap is a method to know the suit model of the pls model that we have examine before. it is a procedural step in sem pls analysis.

# Store the summary of the bootstrapped model:
boot_model_htmt <- bootstrap_model(seminr_model = my_model, nboot = 1000)

Bootstrapping model using seminr...

SEMinR Model successfully bootstrapped

sum_boot_model_htmt <- summary(boot_model_htmt, alpha = 0.10)
sum_boot_model_htmt$bootstrapped_HTMT

               Original Est. Bootstrap Mean Bootstrap SD T Stat. 5% CI 95% CI
COMP  ->  LIKE         0.817          0.817        0.035  23.621 0.760  0.873
COMP  ->  CUSA         0.507          0.506        0.057   8.949 0.407  0.595
COMP  ->  CUSL         0.551          0.549        0.060   9.221 0.450  0.648
LIKE  ->  CUSA         0.598          0.599        0.040  14.951 0.528  0.661
LIKE  ->  CUSL         0.752          0.753        0.036  20.711 0.693  0.811
CUSA  ->  CUSL         0.765          0.766        0.032  23.889 0.713  0.818

After the bootstrap we can see the reliability such as alpha, rhoc, AVE, and Rhoa. The reliability model must more than 0,5.

We also look the HTMT test show the result is good. The upper 95% CI shows that the value is not more or equal than the 0,9.

HTMT Test

After the bootstrap we also run the HTMT Test to make sure the model good. all the 95% CI Value is not more than 0,9, meaning the model is good.
